PCB Assembly Services

Shenzhen Grande Electronic offers Full Turn-Key and Partial Turn-Key Circuit Board Assembly Services. We focus on both rigid and flex PCB assembly. In Full Turn-Key PCB, we handle everything including making circuit boards, sourcing components, quality inspection and final assembly. While in partial Turn-Key, you can order the PCBs and partial components, we will fix the remaining parts and assembly for you.

How to get a quote for Circuit Board Assembly Services?

PCBs Quote: You can get a PCB board price instantly after sending Gerber file and requirement. All PCBs will be electrically tested. Click PCB Quote Online to get a quote now.

Labour Assembly online Quote: This is also an instant quote. You can get the labour assembly cost in seconds.  Click PCB Assembly Quote to get a quote now.

BOM Pricing: Send your BOM (Bill of Materials) to sales88@greattong.com , we will email you the BOM price during. BOM must include the quantities, reference designators, manufacturer name and manufacturer part number.










Our PCBA Capabilities:

Supported Capabilities
  Types of Assembly   THD (Thru-Hole Device)
  SMT (Surface-Mount Technology)
  SMT & THD mixed
  2 sided SMT and THD assembly
  Order quantity   1 to 10,000 pcs
  Components   Passives parts, smallest size 0201
  Fine pitch to 5 Mils
  BGA, uBGA, QFN,POP and Leadless chips
  Connectors and terminals
  Component Package   Reels
  Cut tape
  Tube and tray
  Loose parts and bulk
  Board dimensions   Smallest size: 10 x 10mm
  Largest size: 457 x 356mm
  Board shape   Rectangular
  Round
  Slots and Cut outs
  Complex and Irregular
  Board type   Rigid FR-4
  Rigid-Flex boards
  Assembly process   Leaded process
  Lead-Free (RoHS)
  Design file format   Gerber RS-274X
  BOM (Bill of Materials) (.xls, .csv, . xlsx)
  Centroid(Pick-N-Place/XY file)
  Sales and support   Emails
  Phone calls
  Web online quotation for PCB and assembly
  Electrical testing   X-ray Inspection
  AOI (Automated Optical Inspection)
  Functional testing
  Oven profile   Standard
  Custom
  Turnaround time   1-5 days for only PCB assembly
  10-16 days for turnkey PCB assembly


Testing Procedures
Various testing method will be applied to the assembled boards before the final shipment:
    •  Visual inspection: general quality check.
    •  X-ray Inspection: checks for BGAs, QFN and bare circuit boards.
    •  AOI Testing: checks for solder paste, 0201 components, missing components and polarity.
    •  ICT (In-Circuit Test).
    •  Functional test (Following your test procedures).

ISO Certification
Grande’s production facilities are ISO9001:2008 certified to ensure we go beyond your expectations.
