How does a PCB assembly process work?

Time:2018-11-09 09:42:30 Click:

PCB Assembly Process:



PCB Fabrication + Components Sourcing => Drying PCB Board & Some Components before welding=> SMT=>DIP=> PCBA Test



SMT includs:



PCB Uploading=>Glue Dispense=>Solder Paste Printing / Stencil Printing=>Solder Paste Inspection=>Pick & Place=>Reflow Oven=>AOI=>Manual Welding=>Visual Inspection
