Printed Circuit Board (PCB) First Article Assembly

Time:2017-10-10 17:02:04 Click:

Shenzhen Grande Electronic which offers printed circuit board (PCB) first article assembly with the most reasonable prices than any other electronic contract manufacturers. The most significant step for successful layout designing of the PCB is that the first article approval of circuit board by the client. As the approved first article circuit board resolves most of the queries pertaining to fabrication, PCB assembling and its testing. We provide first article assembly for different technology boards.

We have engaged our expert team to cater to the customer needs for varied technologies such as we have an ability to handle extra-large through-hole circuit board, surface-mount and mixed-technology PCBs. We offer superior quality along with fast response for any PCB assembly related queries. On final decision of a technology, further cost is available to discuss with us.

So as to benefit the customers, Shenzhen Grande’s first article assembly service offers the most suitable cost structure to reduce the prototyping costs. Our staff puts their extensive knowledge to serve every client by giving necessary ideas and suggestions on design which is aim to improve the manufacturing process as an additional way to reduce costs and proceed for placement of order.

We as the most efficient electronic contract manufactures accepts orders through various channels. For example, the orders can be placed via email, telephone or through our respective website with a specific details for first article assembly. Furthermore, the instant online quote tool for PCB assembly can not only get the idea of the pricing of PCB assembly but also get information pertaining to inspection methods adopted.

The first article circuit board assembly process is a significant step. Even if a small error in assembly machine setup will lead to multiplication of errors in all circuit boards of current work order. Hence the use of stringent quality inspection techniques which plays a pivotal role in getting the required first article assembled. Don't worry, our engineers are well trained to get the PCB on a test bench along with evidence of concept validation.

Our inspection monitoring team recurrently supervises the PCB assembly process with demonstrated methods for statistical process control. We use modern techniques such as X-Ray inspection for Leadless & BGA components to check the joint soldering. Automatic Optical Inspection (AOI) is used for verification of solder joints, component placement and orientation, etc. If you need any added information regarding quality methods and shipping charges, you can send an email to sales team at sales88@greattong.com

Unlike other circuit board assemblers we do not burdened our clients with any additional charges. And this is relevant from the fact that we do not charge any extra prices for quick shipping of first assembled PCB in addition to modification of services.

We avoid charging additional costs for any modification of services for remaining circuit board assembling. Once the customer receives first article PCB assembly boards, it is required to test the boards and inform us about any changes required by preferred communication method. The modifications are done with no additional costs for programming or set-up for circuit board assembly. Different means of communication can be used for further coordination and can also contact us for online quote queries.

For effective end delivery, we coordinate with our customers through various channels by means of our specialized team. We arrange an online teleconference with the client for reviewing the circuit board assembled and discuss the probable changes with respect to Design for Manufacturability (DFM). We also use other communication methods to discuss any assembling issues along with meeting the specific requirements of our clients.
